HID iCLASS SE - Overview; Features; Table 1: Feature Overview

iCLASS SE Reader Module Hardware Developer’s Guide, SE3200-902, Rev. C.1
Page 11 of 52 February 2014
2 Overview
2.1 Features
Table 1: Feature Overview
Type
Feature
Comment
RF Interface
ISO/IEC14443
ISO/IEC14443 Type A&B up to 848kbps,
MIFARE Classic, MIFARE DESFire 0.6 & EV1
ISO/IEC15693 CSN only
Pico15693 ISO/IEC15693 with proprietary protocol
Pico14443B ISO/IEC14443 Type B with proprietary protocol
HID iCLASS ISO/IEC14443 and ISO/IEC15693 mode
FeliCa CSN only
HID Prox
SE32x0APx only
Indala Prox
Host Interfaces
SPI
UART Suggested host interface
Wiegand Output only binary interface
Environmental
Properties
Operating
Temperature
-25°C to 65°C
Storage Temperature -45°C to 85°C
Humidity 0-90% non condensing
Certifications
FCC & IC FCC and Industry Canada Modular Approval
CE Marking
R&TTE Directive (Emissions, Indirect ESD, RF
Immunity)
RoHS & REACH
UL Recognized
Component
UL 294
GSA SE32x0Axx-G3.0 only (in process)
