HID iCLASS SE - Typical Read Ranges with HID Multi Technology Cards; ULPM Card Detection Range; Table 18: Typical Read Ranges 4090 A10 HF Antenna - HID Multi Technology Cards

iCLASS SE Reader Module Hardware Developer’s Guide, SE3200-902, Rev. C.1
February 2014 Page 36 of 52
Transponder /
IC Type
Manufacturer
Form
Factor
Standard /
Modulation Scheme
SRF
[MHz]
Typical Read
Range [mm]
FeliCa RC-S915
Sony
Corporation
ID1 Card FeliCa
13.57 35
13.58 35
7.3.3 Typical Read Ranges with HID Multi Technology Cards
For this read range tests the serial number of each individual HF chip inside the multi
technology card was read. For Prox read ranges, see Section 7.5 6500-101-03 Prox
Antenna.
Note: Read range varies depending on the transponders antenna size, design, SRF and
Quality.
Table 18: Typical Read Ranges 4090A10 HF Antenna - HID Multi Technology
Cards
Card Type
Manufacturer
Standard /
Modulation Scheme
Chip
Typical Read
Range[mm]
MIFARE / Prox HID Global ISO/IEC14443 (Type A) MIFARE 40
DESFire / Prox HID Global ISO/IEC14443 (Type A) DESFire 35
iCLASS /
MIFARE / Prox
HID Global
ISO/IEC14443 (Type A) MIFARE 45
ISO/IEC15693 iCLASS 60
iCLASS /
DESFire / Prox
HID Global
ISO/IEC14443 (Type A) DESFire 40
ISO/IEC15693 iCLASS 50
7.3.4 ULPM Card Detection Range
The card detection range in Ultra Low Power Mode depends on the loading effect the
transponder imposes on the iCLASS SE Reader Module’s antenna. That means that
cards with lower loading effect will generally have a shorter detection range.
