4.3 Connector Types
4.3.1 SE3210Axx Connector Types
The following connectors are used for interconnection with host and antenna.
Table 7: SE3210 Connector Types
Connector
Function
Type / Counterpart
P301
Power supply and host
interfaces
Manufacturer: Molex
Type: PicoBlade
Part Number: 53048-0810
Mates with: Molex 05102 series
P701
Wiegand and I/Os
Manufacturer: Molex
Type: PicoBlade
Part Number: 53048-0910
Mates with: Molex 05102 series
P702
Alternative connection to
P301 and P702
Manufacturer: Hirose Electric
Type: Board to Board
Part Number: DF12D(5.0)-30DP-
0.5 VDC
Mates with: DF12-DS series
P401
HF Antenna
Manufacturer: Molex
Type: PicoBlade
Part Number: 53048-0510
Mates with: Molex 05102 series
E501 / E502
Prox Antenna
Direct connect solder to module - no connector
(It is recommended that the Prox antenna also
be strain relieved by applying epoxy to adhere
the antenna leads to the module for non potted
integrations)
4.3.2 SE3200Axx Interconnect
The SE3200Axx is designed as the smallest form factor possible. This module offering
was designed to be header mounted on a host board utilizing the P301 and P701
through-hole connections. Use P702 as an alternative board-to-board connection if
preferred.
Some header sources are:
• Cherng Weei
• HLCO
Each company’s part drawings are located on the DTK micro-site.
