4 Mechanical Specifications
The following section details the mechanical specifications for the iCLASS SE Reader
Module and its connectors. Detailed drawings are also available at the iCLASS SE
Reader Module micro-site.
4.1 SE3200Axx
This form factor is compatible with OEM75 model 3141ADx.
Figure 4: SE3200 Mechanical Drawing
