iCLASS SE Reader Module Hardware Developer’s Guide, SE3200-902, Rev. C.1

February 2014 Page 48 of 52

7.5.3 Typical Read Ranges

The measured read ranges are indications only. Read range varies due to transponder

antenna size and quality, as well as environmental effects.

Table 32: Typical Read Ranges 6500-101-03 Prox Antenna

Transponder

Modulation Scheme

Typical Read Range [mm]

HID Prox FSK 40

HID DuoProx II FSK 60

MIFARE / HID Prox Combo Card FSK 60

Indala Prox PSK 55
