Studio Command Series User Manual 1
Chapter 1:
Product Overview
Studio Command 1200 Studio Command 700 Studio Command H
Input Voltage 200-230 V 100-230 V 100-230 V
Lamp 1200 MSR* 700 MSR* 1000 W
Color Temperature 5900 K 5600 K 3200 K
Fixture Output 15,000 lumens 11,000 lumens 5,500 lumens
The Studio Command Series offer powerful washlights featuring a large exiting beam with a
compact head. All models use a patented lenticular array optical system to enhance the
homogeneity of the projected light. The moving yoke fixtures feature an adjustable field angle
from 18 to 32 degrees, and a CMY dichroic color-mixing system that provides rapid and quiet
color changes.
Studio Command 1200 and 700 models use proven Philips long-life MSR lamps. These models
also offer a variable mechanical and electronic strobe, boosted with the Light Burst™ effect, and
a mechanical douser for smooth fade to black. The Studio Command 1200/700 models uses 14
channels on a DMX link.
The Studio Command H model offers a Tungsten source and works with standard theater
dimming racks. The H model requires 13 DMX channels plus one channel dedicated to the
dimmer.
All Studio Command fixtures provide an option for standalone programming and support
TalkBack
™
technology that allows any DMX console supporting TalkBack protocol to remotely
access the Studio Command onboard menu system.
Model Comparison
* 7200°K MSR 1200/2 and MSR 700/2 lamps are approved alternatives
