CHAPTER 4
Fixture Programming
50 Studio Command Series User Manual
Cyan, Magenta, and Yellow Parameters
Cyan, Magenta and Yellow parameters determine color mixing options. The color options
available are determined by the Color Function parameter DMX value you choose.
Zoom Parameter
The Zoom parameter is controls the Zoom range from 18° at a DMX value of 0 to 33° at a DMX
value of 255.
Shutter Function Parameter
Studio Command 1200/700 Models
Basic Shutter functions can be selected when no lamp or dimming functions are set in the
Control channel.
Shutter Function Description
Close Closes shutter
Periodic Strobe Strobes beam at specified intervals. Periodic strobes transition
smoothly from mechanical strobes to electronic strobes. Mechanical
strobes support 1-4 Hz operation. Electronic strobes support 5-33Hz
operation.
Random Strobe Allows all Studio Command Fixtures on the DMX link to strobe their
shutters at random times.
Random/Synchronous Strobe Allows all Studio Command Fixtures on the DMX link to strobe their
shutters at random times in unison.
Ramp Open/Snap Shut Opens shutter at variable speeds, then snaps shut at full speed
Snap Open/Ramp Shut Opens shutter at full speed, then ramps shut
Ramp Open/Ramp Shut Opens shutter at variable speeds, then ramps shut
Random Ramp Open/Snap Shut Opens shutter at random variable speeds, then snaps shut at full
speed
Random Snap Open/ Ramp Shut Opens shutter at full speed, then ramps shut at random variable
speeds
Open Opens shutter
