CHAPTER 1
Product Overview
2 Studio Command Series User Manual
Studio Command
™
Features
Fixture
All Models
• 540° pan 240° tilt
• Optical encoders to automatically correct the beam’s position if the fixture’s head is jarred
from its programmed position.
• Shutter construct parameters including ramp, snap, and synchronous strobing functions.
• Time code synchronization in stand-alone mode via master/slave links to any combination of
xSpot
®
Xtreme, Technobeam
®
, Studio Spot
®
, Studio Color
®,
Studio Color
®
250, Studio
Spot
®
250, Studio Beam
®
, and Studio Command™ fixtures.
• DMX analyzer for easy DMX troubleshooting.
• Lamp interlock douses the lamp if the lamp cap is opened while the lamp is on.
• Remote fixture power up and shut down.
Studio Command 1200/700 Model Only
• Smooth full-field dimming without changing color temperature or beam shape.
• Electronic strobe in addition to a variable conventional strobe to 10 Hz.
• Full optical dimming and fade-to-black.
• Light burst lamp boosting and lightning effects.
Operation
• High-resolution DMX512 programming control.
• TalkBack protocol support for remote fixture control.
• Fat output beam (8 inches (200 mm) in diameter)
• Integral, fully variable zoom adjustable from 8°–13° beam angle and an 18°–32° field angle.
• Fully dichroic colors that never fade
• Full control over color mixing from smooth, stepless movement (allowing slow, imperceptible
color fades) to rapid snap color changes
• Quiet performance even during snap color changes
• Even, soft-edged wash with good beam distribution for easy blending
• Live color fading from one color to another at any speed
• On-board Preset DMX programming via the fixture’s menu system for stand-alone operation.
• Easy-to-program alphanumeric LED (light emitting diode) display.
• Two user Preset modes (A and B), each with an on-board 16-scene memory for a total of 32-
scene memory per fixture in stand-alone mode.
• DMX macro channel factory-programmed with four Internal Effects™ macros.
