CHAPTER 1
Product Overview
Studio Command Series User Manual 7
Cable and Connector Specifications
DMX data cables: Belden
®
9841 or equivalent (meets specifications for EIA RS-485
applications) with the following characteristics:
• 2-conductor twisted pair plus a shield
• maximum capacitance between conductors - 30 pF/ft.
• maximum capacitance between conductor and shield - 55 pF/ft.
• maximum resistance of 20Ω / 1000 ft.
• nominal impedance 100-140Ω
DMX data connectors, 1200/700 Model: 3-pin or 5-pin male and female XLR connectors
DMX data connectors, H Model: 5-pin male and female XLR connectors
DMX data terminators: Male XLR connector with 120 ohm terminator
Lamp Specifications
Studio Command 1200 Studio Command 700
Studio Command H
Primary Lamp Alternate Lamp Primary Lamp Alternate Lamp
Lamp:
PHILIPS
MSR1200
PHILIPS
MSR1200/2
PHILIPS
MSR700
PHILIPS
MSR700/2
PHILIPS
7002 Y
Luminous Flux 110,000 lm 110,000 lm 56000 lm 55000 lm
29,000 lm
Arc Length 10 mm 10 mm 8 mm 8 mm N/A
Color
Temperature
5900 K 7200 K 5600 K 7200 K 3200 K
Lamp Life 50% 800 hrs 800 hrs 1000 hrs 1000 hrs 250 hrs
CRI 95 85 95 80 100
CIE
X=.325;
Y=.320
X=.302;
Y=.320
X=.330;
Y=.330
X=.302;
Y=.320
