Appendix A
Studio Command™ DMX Protocol
Studio Command Series User Manual 75
Note : The pan and tilt coarse channels set the center position of the position
macro. The Mspeed channel is used to control the speed of the macros
With the Mspeed set at the default value of DMX 0-4 all internal effects
complete moves at approximately 2.5 seconds. This provides a pleasing
look for those customers that do not want the additional variation given
by using the Mspeed channel.
With the Mspeed set between DMX 5-255 all internal effects complete
moves at the selected Mspeed time (up to 25 seconds).
Those fixture types that support On Board Programming also support the
Internal Effects as part of the On Board programming features. The
Internal Effects will operate as an additional programming parameter
labeled MACR.
14 Control
The Control channel should not be crossfaded.
Safe (disables all Control settings) 0-9 0-4 00-09
Pan & Tilt MSpeed Off 10-19 4-7 0A-13
Set Shutter channel to 0 for access to the following commands.
Display Off 20-28 8-11 14-1C
Display Dim 30-38 12-15 1E-26
Display Bright 40-48 16-19 28-30
Home 60-68 24-27 3C-44
Lamp On 80-88 31-35 50-58
Lamp Off 90-98 35-38 5A-62
Shutdown (send for 5 seconds) 120-130 47-51 78-82
Lamp Functions
Lamp assisted strobes (Periodic and Random
strobe functions are lamp assisted. Ramp functions
are not lamp assisted.)
134-137 53-54 86-89
Lamp functions (modifies the shutter channel) 138-141 54-55 8A-8D
Lamp/mechanical dimming (Lamp output will vary
from a minimum to 1200 Watts as the mechanical
dimming ranges from 0-100%)
142-145 56-57 8E-91
Lamp only dimming (Electronic dimming only from
a minimum to 1200 Watts.)
146-149 57-58 92-95
To be determined 150-255 59-100 96-FF
Channel Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
To Next Page
