Appendix A
Studio Command™ DMX Protocol
Studio Command Series User Manual 81
Note 1: The pan and tilt coarse channels set the center position of the position
macro. The Mspeed channel is used to control the speed of the macros
With the Mspeed set at the default value of DMX 0-4 all internal effects
complete moves at approximately 2.5 seconds. This provides a pleasing
look for those customers that do not want the additional variation given
by using the Mspeed channel.
With the Mspeed set between DMX 5-255 all internal effects complete
moves at the selected Mspeed time (up to 25 seconds).
Those fixture types that support On Board Programming also support the
Internal Effects as part of the On Board programming features. The
Internal Effects will operate as an additional programming parameter
labeled MACR.
12
Macro
(Note 1)
Macro Off 0-5 0-2 00-05
Pan sweep, small to large angle 6-62 2-24 06-3E
Macro Off 63-65 25-25 3F-41
Tilt sweep, small to large angle 66-122 26-48 42-7A
Macro Off 123-125 48-49 7B-7D
Clockwise circle, small to large 126-160 49-63 7E-A0
Macro Off 161-163 63-64 A1-A3
Counterclockwise circle, small to large 164-198 64-78 A4-C6
Reserved 199-255 78-100 C7-FF
13 Control
The Control channel should not be crossfaded.
Safe (disables all Control settings) 0-9 0-4 00-09
Pan & Tilt MSpeed Off 10-19 4-7 0A-13
Set Shutter channel to 0 for access to the following commands.
Display Off 20-28 8-11 14-1C
Display Dim 30-38 12-15 1E-26
Display Bright 40-48 16-19 28-30
Home 60-68 24-27 3C-44
Shutdown (send for 5 seconds) 80-130 31-51 50-82
To be determined 131-255 52-100 83-FF
Channel Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
