HIKVISION DS-2CD2432F-I Installation Manual

Installation Manual of Network Camera
18
1). Loosen the pan nut to adjust the pan angle [0 °-360°].
2). Loosen the knob on the ceiling mount to adjust the tilt angle [0°-±45°].
8. Adjust the Lens
1). Connect the VIDEO OUT interface of the camera to the debugging monitor.
2). Adjust the focus lever to obtain a perfect image on the monitor.
Tilt Adjust Nut
Pan Adjust Nut
Figure 2-17 Adjust the Surveillance Angle
 Installing the SD Card
● Insert the SD card to the SD card slot to get it installed.
● Push the inserted SD card slightly to get it sprung by its built-in springing to remove it.
Figure 2-18 Install the SD Card
SD Card
