HIKVISION DS-2CD2432F-I

Installation Manual of Network Camera
32
Figure 3-25 Drill Template
2. Fix the ceiling mount to the ceiling with screws.
Figure 3-26 Fix the Ceiling Mount
3. Route the cables through the cable hole on the ceiling.
If required, you can rotate the side outlet on the mounting base to remove it and route the cables
through the side outlet.
Ceiling
Ceiling Mount
