HIKVISION DS-2CD2432F-I

Installation Manual of Network Camera
33
Figure 3-27 Side Outlet
4. Insert the three screws on the mounting base into the corresponding holes on the ceiling mount.
5. Rotate the mounting base clockwise to secure the dome camera to the ceiling mount.
Unlock Button
Screw
Hole
Figure 3-28 Install the Dome Camera
To uninstall the dome camera, press the lock button and rotate the mounting base
counterclockwise.
Side Outlet
