User Manual of DS-7200-SH/SV&DS-7300-SH Series DVR
29
Figure 3.1 Right-click Menu
Table 3.3 Mouse Operation in Live View
Enter the main menu of the system by right-clicking the mouse.
Switch to the single full screen by choosing channel number from the dropdown list.
Adjust the screen layout by choosing from the dropdown list.
Switch to the previous screen.
Switch to the next screen.
Enable/disable the auto-switch of the screens.
Note: The dwell time of the live view configuration must be set before using Start
Auto-switch.
Start all-day normal recording or motion detection recording for all channels.
Set the video output mode to Standard, Bright, Gentle or Vivid.
Play back the video of the selected channel.
Switch to the auxiliary output mode and the operation for the main output is disabled.
Note: If you enter Aux monitor mode and the Aux monitor is not connected, the mouse
operation is disabled; you need to switch back to the Main output with the VOIP/MON
button on IR remote control and then press the Enter button.
Note: If the corresponding camera supports intelligent function, the Reboot Intelligence option is included
when right-clicking mouse on this camera.
3.2.3 Using an Auxiliary Monitor
Certain features of the Live View are also available while in an Aux monitor. These features include:
• Single Screen: Switch to the single full screen by choosing channel number from the dropdown list.
• Multi-screen: Adjust the screen layout by choosing from the dropdown list.
• Previous Screen: Switch to the previous screen.
• Next Screen: Switch to the next screen.
• Quick Set: Set the video output mode to Standard, Bright, Gentle or Vivid.
• Menu Output Mode: Select the menu output mode to HDMI/VGA, Main CVBS or Auto.
• Main Monitor: Switch to the Main Output mode and the operation for the auxiliary output is
disabled.
