User Manual of DS-7200-SH/SV&DS-7300-SH Series DVR
96
Figure 7. 11 Checkup of Export Result using USB Writer
7.1.3 Backing up by Event Search
Purpose:
Back up event-related record files using USB devices (USB flash drives, USB HDDs, USB writer), or SATA
writer. Quick Backup and Normal Backup are supported.
Note: Backup by alarm input search is supported by DS-7300HWI/HFI-SH only.
Steps:
1. Enter Export interface.
Menu>Export>Event
2. Select Motion or Alarm Input as the event type.
Note: The following steps have introduced the backup by motion detection triggered record files.
Perform the same operation for the backup by alarm triggered record files.
3. Set the start time and end time of the record files.
4. Select the camera (s) for searching.
Figure 7.12 Event Search for Backup
5. Click Search button to enter the Search Result interface.
