User Manual of DS-7200-SH/SV&DS-7300-SH Series DVR

165

13.1 Configuring General Settings

Purpose:

You can configure the BNC output standard, VGA/HDMI output resolution, mouse pointer speed, etc.

Steps:

1. Enter the General Settings interface.

Menu > Configuration > General

2. Select the General tab.

Figure 13.1 General Settings Interface

3. Configure the following settings:

• Language: The default language used is English.

• CVBS Output Standard: Select the CVBS output standard to NTSC or PAL, which must be the

same with the video input standard.

• Resolution: Select the VGA/HDMI output resolution, which must be the same with the resolution

of the monitor screen.

• Time Zone: Select the time zone.

• Date Format: Set the date format.

• System Date: Select the system date.

• System Time: Set the system time.

• Mouse Pointer Speed: Set the speed of mouse pointer; 4 levels are configurable.

• Enable Wizard: Enable/disable the Wizard when the device starts up.

• Enable ID Authentication: Enable/disable the use of the login password.

4. Click the Apply button to save the settings.

13.2 Configuring RS-232 Serial Port

Note: The RS-232 serial port is supported by DS-7300HWI/HFI-SH models only.

Purpose:

The RS-232 port can be used in two ways:

• Parameters Configuration: Connect a PC to the device through the PC serial port. Device parameters can be

configured by using software such as HyperTerminal. The serial port parameters must be the same as the device’s

when connecting with the PC serial port.
