User Manual of DS-7200/7300/8100 Series DVR
46
Time Segment 1, the Time Segment 2 is remained as the Others.
2. Select the mode from the drop-down menu according to different light conditions.
Four modes are selectable:
Standard: in general lighting conditions (default).
Indoor: the image is relatively smoother.
Dim Light: the image is smoother than the other three modes.
Outdoor: the image is relatively clearer and sharper. The degree of contrast and saturation is high.
Figure 3. 5 Image Settings
3. Adjust the image parameters including the brightness, contrast, saturation, hue, sharpness level and
denoising level by moving the sliding bar or increasing/decreasing the value.
The adjustable value range is 0~255 for the brightness, contrast, saturation and hue, 0~15 for the
sharpness level and 0~5 for the denoising level.
4. Copy image parameters.
You can click the Copy button to enter the Copy to interface to copy the image parameters of the
current camera to other analog camera (s)
You can click the Restore button to restore the current image settings to default parameters.
Task2: Configure image settings for the IP camera
Steps:
1. On the Image Settings menu, you can set the image parameters including the brightness, contrast,
saturation and hue in the Custom mode.
