DS-7700NI-SP/9000/9600 Series HDVR/NVR User’s Manual
33
Figure 23 PTZ Control Mode
3. Control the PTZ by using PTZ control buttons. Pan and tilt PTZ by clicking on the directional
buttons. Zoom in and out using the Zoom In/Out buttons and recall presets, patrols and patterns
by clicking the corresponding icons.
Below is the description of the PTZ control icons:
Direction buttons and the auto-cycle button
Zoom+/Zoom-
Focus+/Focus-
Iris+/Iris-
The speed of the PTZ movement
Light On/Off
Wiper On/Off
3D-Zoom
Image Centralization
Menu
4. Click the Close icon to return to the Live Feed mode.
