DS-7700NI-SP/9000/9600 Series HDVR/NVR User’s Manual
34
Note:
PTZ parameters for the camera must be set correctly before the PTZ can be controlled.
Digital Zoom Mode:
Enable digital zoom on the selected channel. Once enabled, the regular feed will be shown in the lower
right corner while the zoomed in view will be shown on the full screen. The zoomed in region may be
changed by moving the red rectangle in the regular feed window, as shown in the Figure 24. Right click
to back to the Live Feed mode.
Figure 24 Digital Zoom
Image Settings:
Set the image mode and image parameters like brightness, contrast, saturation, hue and so on for selected
display. To adjust the image settings of a display as following steps:
Steps:
1. Select display.
2. Click the Image Settings icon. This will bring up the Image Settings menu, analog camera is
shown in Figure 25, IP camera is shown in Figure 26.
Figure 25 Analog Camera Image Settings Menu
