HIKVISION DS-K3G501X-R-M-DM55 - 3 Installation; 3.1 Disassemble Pedestals

Figure 2-1 System Wiring Diagram
Note
●
High voltage: AC power input
Low voltage: network cable (CAT5E, CAT6 or CAT6E),
interconnecng data cable and interconnecng power cable.
●
The supplied interconnecng power cable length is 3.75 m, if
necessary, you can contact the sales person to replace it with
a 5.5 m cable.
●
The suggested inner diameter of the high and low voltage
conduit is larger than 30 mm. If the switch
(oponal) is
selected, the suggested inner diameter of the high voltage
conduit is larger than 30 mm.
●
If you want to bury both of the high voltage cable and the
interconnecng cable, the two cables should be in separated
conduits to avoid interference.
●
If more peripherals are required to connect, you should
increase the conduit diameter or bury another conduit for
the external cables.
3 Installaon
3.1 Disassemble Pedestals
Before installaon, you should use the key to open the pedestals.
View the pictures below to nd the lock holes.
Figure 3-1 Lock Holes
2
