Figure 4-2 Serial Port
4.2 Wiring
Scan the QR code to view the wiring guide video.
4.3 Wiring Electric Supply
Wire electric supply with the power switch or power adapter in
the pedestal. Terminal L (brown) and terminal N (Blue) are on the
switch, while terminal PE should connect to a ground wire (yellow
and green wire).
For product with power switch, the wiring diagram is as follows:
For product with power adapter, the wiring diagram is as follows:
Warning
Terminal PE should connect to a ground wire to avoid hazard
when people touching the device.
5
