The switching power supply can select the input voltage of 220 V
or 110 V by the DIP switch, and the default seng is 220V. Please
adjust the DIP switch based on the actual AC voltage to avoid
damaging the equipment.
Note
The cable bare part should be no more than 8 mm. If possible,
wear an insulaon cap at the end of the bare cable. Make sure
there's no bare copper or cable aer the wiring.
The Terminal L and the Terminal N cannot be wired reversely.
Do not wire the input and output terminal reversely.
To avoid people injury and device damage, when
tesng, the
ground resistance of the equipotenal points should not be
larger than 2 Ω
4.4 Terminal Descripon
4.4.1 Lane Control Board Terminal Descripon
The lane control board contains power input interface, exit
buon and re input interface, access control board interface,
debugging port, indicator interface, etc.
The picture displayed below is the lane control board diagram.
4.4.2 Access Control Board Terminal
Descripon
Access control board is mainly used for authority idencaon in
places with high security levels such as public security or judicial
place, external device accessing, and
communicaon with the
upper plaorm and lane controller.
6
