HIKVISION DS-KD8003-IME2 User Manual

1 Introducon
●
The PMR module is designed for hearing-impaired users,
suitable for mul-module scenarios.
●
The PMR indicator will always be lit up if the device is in
service.
●
The calling indicator will keep yellow when there's an incoming
call.
●
The two-way audio indicator will keep white when there's an
ongoing two-way audio
conversaon.
●
The unlock indicator will keep blue when the door is opening.
2 Appearance
Main Unit
Figure 2-1 Main Unit Appearance
Table 2-1 Appearance Descripon
No. Descripon
1 Microphone
2
Low Illuminaon IR Supplement
Light
3 Built-in Camera
4 Loudspeaker
5 Call Buon
1

HIKVISION DS-KD8003-IME2 Specifications

General

Megapixel	2 MP
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Viewing angle, vertical	96 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	180 °
Video codecs	H.264
Number of buttons	1 buttons
Streaming capability	Yes
Connectivity technology	Wired
Maximum number of cameras supported	-
Voice codecs	G.711u
Product color	Black, Grey
International Protection (IP) code	IP65
Operating relative humidity (H-H)	10 - 95 %
Door station operating temperature (T-T)	-40 - 60 °C
Indoor unit included	No
Outdoor unit power type	DC
Display diagonal	- \
Harmonized System (HS) code	85176920
