HIKVISION DS-KD8003-IME2 User Manual

Note
●
The dimension of two-module mounng frame (W × H × D) is:
321 mm × 107 mm × 33 mm.
●
The dimensions above are for reference only. The actual size
can be slightly dierent from the theorecal dimension.
Steps
1. Paste the installaon scker 1 onto the wall. Make sure the
scker is placed horizontally via measuring with the gradienter.
2. Drill 4 holes according to the screw holes on the
scker.The
suggested size of hole is 6 (diameter) × 25 (depth) mm. The
suggested length of cables le outside is 270 mm.
Figure 4-17 Drill Screw Holes
3.
Remove the scker and insert the expansion sleeves into the
screw holes.
4. Fix the
mounng frame onto the wall with 4 expansion bolts.
Figure 4-18 Fix the Mounng Frame
Note
The mounng frame should be placed exactly as shown below
for this step. The tamper plate should be at the low right of the
rst grid.
20

HIKVISION DS-KD8003-IME2 Specifications

General

Megapixel	2 MP
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Viewing angle, vertical	96 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	180 °
Video codecs	H.264
Number of buttons	1 buttons
Streaming capability	Yes
Connectivity technology	Wired
Maximum number of cameras supported	-
Voice codecs	G.711u
Product color	Black, Grey
International Protection (IP) code	IP65
Operating relative humidity (H-H)	10 - 95 %
Door station operating temperature (T-T)	-40 - 60 °C
Indoor unit included	No
Outdoor unit power type	DC
Display diagonal	- \
Harmonized System (HS) code	85176920
