Figure 4-1 Terminal Diagram
The descripons of the terminals are as follows:
Table 4-1 Terminal
Descripons
Group No. Funcon Color Name Descripon
Group A A1 Power Input Red +12 ~ 24 VDC Power Supply
A2 Black GND Ground
Group B B1 Alarm Input Yellow/Blue IN1 Alarm Input 1
Face Recognion Terminal User Manual
9

HIKVISION Ultra Series Specifications

General

Brand	HIKVISION
Model	Ultra Series
Category	Touch terminals
Language	English
