Installation MACH1000
Release
06
03/2021
61
c. With F/O adapter compliant with IEEE 802.3-2002 Clause 38 (single-mode fiber offset-launch mode conditioning patch cord).
d. With F/O adapter compliant with IEEE 802.3-2002 Clause 38 (single-mode fiber offset-launch mode conditioning patch cord).
e. Including 2.5 dB system reserve when compliance with the fiber data is observed.
Product code
M-SFP-BIDI...
Mode Wave length
TX
Wave length
RX
Fiber System
attenuation
Example for F/O
cable length
a
a. Including 3 dB system reserve when compliance with the fiber data is observed.
Fiber
attenuation
Dispersion
Type A LX/LC EEC SM 1310 nm 1550 nm 9/125 µm 0 dB ... 11 dB 0 km ... 12.43 mi
(0 km ... 20 km)
0.4 dB/km 3.5 ps/(nm×km)
Type B LX/LC EEC SM 1550 nm 1310 nm 9/125 µm 0 dB ... 11 dB 0 mi ... 12.43 mi
(0 km ... 20 km)
0.25 dB/km 19 ps/(nm×km)
Type A LH/LC EEC LH 1490 nm 1590 nm 9/125 µm 5 dB ... 24 dB 14.29 mi ... 49.71 mi
(23 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
Type B LH/LC EEC LH 1590 nm 1490 nm 9/125 µm 5 dB ... 24 dB 14.29 mi ... 49.71 mi
(23 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
Table 10: F/O port (bidirectional Gigabit Ethernet SFP transceiver)
Product code Mode
a
Wave length Fiber System
attenuation
Example for F/O line
length
b
Fiber
attenuation
BLP/Dispersion
M-FAST-SFP-MM/LC... MM 1310 nm 50/125 µm 0 dB ... 8 dB 0 mi ... 3.11 mi
(0 km ... 5 km)
1.0 dB/km 800 MHz×km
M-FAST-SFP-MM/LC... MM 1310 nm 62.5/125 µm 0 dB ... 11 dB 0 mi ... 2.49 mi
(0 km ... 4 km)
1.0 dB/km 500 MHz×km
M-FAST-SFP-SM/LC... SM 1310 nm 9/125 µm 0 dB ... 13 dB 0 mi ... 15.53 mi
(0 km ... 25 km)
0.4 dB/km 3.5 ps/(nm×km)
M-FAST-SFP-SM+/LC... SM 1310 nm 9/125 µm 10 dB ... 29 dB 15.53 mi ... 40.39 mi
(25 km ... 65 km)
0.4 dB/km 3.5 ps/(nm×km)
M-FAST-SFP-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 29.20 mi ... 64.62 mi
(47 km ... 104 km)
0.25 dB/km 19 ps/(nm×km)
Table 11: F/O port 100BASE-FX (SFP Fiber Optic Fast Ethernet Transceiver)
