Hirschmann MACH1000 Series User Manual

62
Installation MACH1000
Release
06
03/2021
M-FAST-SFP-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 14.29 mi ... 86.99 mi
(55 km ... 140 km)
0.18 dB/km
c
18 ps/(nm×km)
SFP-FAST-MM/LC
d
MM 1310 nm 50/125 µm 0 dB ... 8 dB 0 mi ... 3.11 mi
(0 km ... 5 km)
1.0 dB/km 800 MHz×km
SFP-FAST-MM/LC EEC
d
MM 1310 nm 62.5/125 µm 0 dB ... 11 dB 0 mi ... 2.49 mi
(0 km ... 4 km)
1.0 dB/km 500 MHz×km
SFP-FAST-SM/LC
d
SM 1310 nm 9/125 µm 0 dB ... 13 dB 0 mi ... 15.53 mi
(0 km ... 25 km)
0.4 dB/km 3.5 ps/(nm×km)
SFP-FAST-SM/LC EEC
d
SM 1310 nm 9/125 µm 0 dB ... 13 dB 0 mi ... 15.53 mi
(0 km ... 25 km)
0.4 dB/km 3.5 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
c. With ultra-low-loss optical fiber.
d. You will find further information on certifications on the Internet on the Hirschmann product pages (www.hirschmann.com).
Product code Mode Wave length Fiber System
attenuation
Example for F/O
cable length
a
a. Including 3 dB system reserve when compliance with the fiber data is observed.
Fiber attenuation BLP/Dispersion
-FF MM 820 nm 50/125 µm 0 dB ... 9.5 dB 0 mi ... 1.31 mi
(0 km ... 2.1 km)
3.0 dB/km 400 MHz×km
-FF MM 820 nm 62.5/125 µm 0 dB ... 12.5 dB 0 mi ... 1.86 mi
(0 km ... 3 km)
3.2 dB/km 200 MHz×km
Table 12: F/O port 10BASE-FL
Product code Mode
a
Wave length Fiber System
attenuation
Example for F/O line
length
b
Fiber
attenuation
BLP/Dispersion
Table 11: F/O port 100BASE-FX (SFP Fiber Optic Fast Ethernet Transceiver)
