Installation MACH1000
Release
06
03/2021
63
MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
Product code Mode Wave length Fiber System
attenuation
Example for F/O
cable length
a
a. Including 3 dB system reserve when compliance with the fiber data is observed.
Fiber attenuation BLP/Dispersion
-JJ, -MM, -NN, -BB MM 1300 nm 50/125 µm 0 dB ... 8 dB 0 mi ... 3.11 mi
(0 km ... 5 km)
1.0 dB/km 800 MHz×km
-JJ, -MM, -NN, -BB MM 1300 nm 62.5/125 µm 0 dB ... 11 dB 0 mi ... 2.49 mi
(0 km ... 4 km)
1.0 dB/km 500 MHz×km
-VV, -UU SM 1300 nm 9/125 µm 0 dB ... 16 dB 0 mi ... 18.64 mi
(0 km ... 30 km)
0.4 dB/km 3.5 ps/(nm×km)
-LL LH 1550 nm 9/125 µm 3 dB ... 29 dB 8.70 mi ... 64.62 mi
(14 km ... 104 km)
0.25 dB/km; 19 ps/(nm×km)
-GG LH 1550 nm 9/125 µm 14 dB ... 47 dB 41.63 mi ... 109.36 mi
(67 km ... 176 km)
0.25 dB/km 19 ps/(nm×km)
Table 13: F/O port 100BASE-FX (DSC/DST fiber optic Fast Ethernet Transceiver)
10/100/1000 Mbit/s twisted pair port
Length of a twisted pair segment max. 328 ft (100 m) (for Cat5e cable)
Table 14: Network range: 10/100/1000 Mbit/s twisted pair port
