Hirschmann MACH1000 Series

64
Installation MACH1000
Release 06 03/2021
 Power consumption/power output
Name Maximum
power
consumpti
on
Maximum
power output
Basic devices
MAR1020-... basic device (without Fast Ethernet module) 7.5 W 25.6 Btu (IT)/h
MAR1030-... basic device (incl. 2 × Gigabit Ethernet module
combo ports, without Fast Ethernet module)
10.5 W 35.9 Btu (IT)/h
MAR1x3y-4O... Basic device (x = 0 or 1, y = 0 or 2) 11.5 W 39.2 Btu (IT)/h
MAR1x3y-4T... Basic device (x = 0 or 1, y = 0 or 2) 14.5 W 49.5 Btu (IT)/h
MAR1x3y-OT... Basic device (x = 0 or 1, y = 0 or 2) 13.0 W 44.4 Btu (IT)/h
Fast Ethernet module
additionally per Fast Ethernet FX module 2.0 W 6.9 Btu (IT)/h
additionally per Fast Ethernet TX module 0.4 W 1.4 Btu (IT)/h
additionally per PoE module 38.0 W 130.0 Btu (IT)/h
Examples
MAR1020-
99TTTTTTTTTTTTTTTTTTTTTTTTUG9HPHHXX.X
12.3 W 42.0 Btu (IT)/h
MAR1020-
99TTTTTTTTTTTTMMMMMMMMMMMMUG9HPHHXX.X
21.9 W 74.8 Btu (IT)/h
MAR1020-
99MMMMMMMMMMMMMMMMMMMMMMMMUG9HPHHXX.X
31.5 W 107.5 Btu (IT)/h
MAR1030-
CCTTTTTTTTTTTTTTTTTTTTTTTTUG9HPHHXX.X
15.3 W 52.2 Btu (IT)/h
MAR1030-
CCTTTTTTTTTTTTMMMMMMMMMMMMUG9HPHHXX.X
24.9 W 85.0 Btu (IT)/h
MAR1030-
CCMMMMMMMMMMMMMMMMMMMMMMMMUG9HPHHXX.X
34.5 W 117.8 Btu (IT)/h
MAR1030-
4TMMMMMMMMMMMMMMMMMMMMMMMMUG9HPHHXX.X
38.5 W 131.4 Btu (IT)/h
MAR1032-4TTTRRMMMMMMMMMM
MMMMMMMMMMUGGHPHHXX.X, no PD (powered device)
35.3 W 120.5 Btu (IT)/h
MAR1132-4OTTRRMMMMMMMMMM
MMMMMM9999UGGHPHHXX.X, no PD (powered device)
28.3 W 96.6 Btu (IT)/h
MAR1032-4TTTRRMMMMMMMMMMMM
MMMMMMMMUGGHPHHXX.X, 4 x Class-0 PD (powered
device)
111.3 W 380.5 Btu (IT)/h
MAR1132-4OTTRRMMMMMMMMMMMM
MMMM9999UGGHPHHXX.X, 4 x Class-0 PD (powered device)
104.3 W 356.6 Btu (IT)/h
