Installation SPIDER PL
Release 08 09/2018
Figure 4: Dimensions of device variants SPIDER-PL-40...
18
0.7
113
4.4
4,2
0.1
mm
inch
135
5.3
49
1.9
9,9
0.3
9,9
0.3
SPIDER PL-40-08T1...
SPIDER PL-40-05T1...
135
5.3
39
1.5
SPIDER PL-040-01T1...
135
5.3
39
1.5
9,9
0.3
