Hirschmann SPIDER PL - Dimension Drawings

Installation SPIDER PL
Release 08 09/2018
47
9.2 Dimension drawings
Figure 3: Dimensions of device variants SPIDER PL-20... and SPIDER PL-30...
SPIDER PL-20-04T1...
135
5.3
39
1.5
9,9
0.3
mm
inch
113
4.4
4,2
0.1
18
0.7
135
5.3
56
2.2
9,9
0.3
SPIDER PL-20-08T1...
135
5.3
56
2.2
9,9
0.3
SPIDER PL-20-06T1...
6,65
0.26
114,7
4.52
9,9
0.39
93,97
3.7
163,6
6.44
163,6
6.44
9,9
0.39
61
2.4
SPIDER PL-20-24T1...
SPIDER PL-30-24T1...
SPIDER PL-20-16T1...
mm
inch
