Installation SPIDER PL Release
08
09/2018
51
Electromagnetic field
EN 61000-4-3 10 V/m 10 V/m 20 V/m 10 V/m
IEEE 1613 — — — 35 V/m
Fast transients (burst)
EN 61000-4-4
IEEE C37.90.1
Supply connection ±2 kV ±2 kV ±2 kV ±4 kV
EN 61000-4-4
IEEE C37.90.1
Data line ±4 kV ±4 kV ±2 kV ±4 kV
Voltage surges - DC supply connection
EN 61000-4-5 line/ground ±2 kV ±2 kV ±2 kV ±2 kV
IEEE 1613 line/ground — — — ±5 kV
EN 61000-4-5 line/line ±1 kV ±1 kV ±1 kV ±1 kV
Voltage surges - data line
EN 61000-4-5 line/ground ±1 kV ±1 kV ±2 kV ±2 kV
Conducted disturbances
EN 61000-4-6 150 kHz ... 80 MHz 10 V 10 V 10 V 10 V
Damped oscillation – DC supply connection
EN 61000-4-12
IEEE C37.90.1
line/ground — — — 2.5 kV
EN 61000-4-12
IEEE C37.90.1
line/line — — — 1 kV
Damped oscillation – data line
EN 61000-4-12
IEEE C37.90.1
line/ground — — — 2.5 kV
EN 61000-4-12 line/line — — — ±1 kV
Pulse magnetic field
EN 61000-4-9 — — 300 A/m —
EMC interference immunity Standard
applications
a
Marine
applications
b
Railway
applications
(trackside)
c
Sub-station
applications
d
