Installation SPIDER PL
Release
08
09/2018
-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 29.20 mi ... 64.62 mi
(47 km ... 104 km)
0.25 dB/km 19 ps/(nm×km)
-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 14.29 mi ... 86.99 mi
(55 km ... 140 km)
0.18 dB/km
c
18 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
c. With ultra-low-loss optical fiber.
Product code Mode
a
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
Wave length Fiber System
attenuation
Example for F/O
cable length
b
b. Including 3 dB system reserve when compliance with the fiber data is observed.
Fiber
attenuation
BLP/Dispersion
-M2, -M4 MM 1300 nm 50/125 µm 0 dB ... 8 dB 0 mi ... 3.11 mi
(0 km ... 5 km)
1.0 dB/km 800 MHz×km
-M2, -M4 MM 1300 nm 62.5/125 µm 0 dB ... 11 dB 0 mi ... 2.49 mi
(0 km ... 4 km)
1.0 dB/km 500 MHz×km
-S2 SM 1300 nm 9/125 µm 0 dB ... 16 dB 0 mi ... 18.64 mi
(0 km ... 30 km
0.4 dB/km 3.5 ps/(nm×km)
Table 10: F/O port 100BASE-FX
10/100/1000 Mbit/s twisted pair port
Length of a twisted pair segment max. 328 ft (100 m) (for Cat5e cable)
Table 11: Network range: 10/100/1000 Mbit/s twisted pair port
Product code
M-FAST-SFP-...
Mode
a
Wave length Fiber System
attenuation
Example for F/O cable
length
b
Fiber attenuation BLP/Dispersion
Table 9: Fiber port 100BASE-FX (SFP fiber optic Fast Ethernet Transceiver)
