Hisun 700UTV - Page 62

62
2. bolt
3. Sequently remove the cotter pins, open-groove nuts, cushion
and front wheel hub from the front wheel shaft.
(Attached figure 4-2-6)
Attached figure 4-2-6
1. Cotter pins 3.2×32
2. Open-groove nut M12
3. Direction machine ball
4. Front Sheep horn
5. Front wheel hub
4、Take down the brake plate from the front wheel hub.(Attached
figure4-2-7 ).
