Hisun 700UTV - Page 64

64
Attached figure4-2-9
1. Hexagon BoltM6×12
2. Disk brake oil cup
4.2.2.3 Dismantlethe rear brake plate clip and the rear disk
brake plate
1 、 Dismantle the rear wheel parts(Attached
figure4-2-10)
Attached figure4-2-10
1. Conical Nuts M10
2. Wheel hub
2 、 Remove rear disk brake clip from the rear bridge
gearbox.(Attached figure4-2-11)
