Hisun 700UTV - Page 65

65
Attached figure4-2-11
1、Rear Disk Brake Clip
2、Hexagon BoltM10×30
3. Loose the rear bridge gearbox on the frame,take down
the middle transmission shaft parts.(Attached
figure4-2-12)
Attached figure4-2-12
1. Disk Brake Clip
2. Disk brake plate
3. Middle transmission shaft
4. Take down the disk brake plate installment place from
the rear bridge gearbox.(Attached figure4-2-13)
