Attached figure4-2-13
1. The disk brake plate installment place
2. The rear disk brake plate
5. Dismantle the disk brake plate from the installment
place(Attached figure4-2-14)
Attached figure4-2-14
1.
Rear disk brake plate
4.2.2.4 Dismantle the disk brake vitta
1、Loose the vitta fixed nut on the front arm shaft and
take down the front vitta.(Attached figure4-2-15).
