Maintain method,fix the flexible nut,instead the
damaged nut.
Locking Torque: 30N.m
3、Check all Fuel Pipes for deterioration, distortion, crack,
wear and other hidden defects.
Maintain method,instead the fuel pipes with problems.
4、Check the Brake Plate Clip for distortion, crack, rust
and stuck.
Maintain method,instead the brake plate with problems.
5、Inspect the Disk Brake Shoe for wear condition. Brake shoe
must be replaced when worn out.(Attached figure4-2-19)
Attached figure4-2-19
1、Brake Shoe
Attention: Brake shoe must be replaced
when the thickness is less than 1mm
6、Inspect the Brake Shoe for maximum wear, distortion and
