Remove the tyre for vibration test of the wheel hub. Should the
vibration exceed 1.2mm, the wheel hub must be
replaced.
5、Inspect the four conical bores on the wheel hub. In occasion
of angular distortion or wear,the wheel hub must
be replaced.
The angle of the conical bores is 60°
4.3.2.3 Assembly of wheel
Attach the wheel hub onto the wheel with four pieces of
M10 Conical Nuts and a dustproof lid.
Caution: assemble the wheel in correct direction (shown
as the arrow).
(Attached Figure4-2-22)
