Rotating the bent lever opens the socket cover latch.
4. Press the straight lever down a little to release the edge of the socket
cover. Then open the socket cover as far as it goes.
Chapter 4: Refurbishing an HCP S30 Node
109
HCP S Series Node Refurbishment
Step 17: Unrack, disassemble, and pack the server modules
