EQUIPMENT SPECIFICATIONS
98
11. EQUIPMENT SPECIFICATIONS
Base Station
Voltage input ................................24VDC ±2.5V
DC current input .............................2.5A maximum
Audio distortion ..............................5% maximum level
Outside speaker output.........................3 watts RMS into 8 ohms
Ceiling speaker power .........................3 watts RMS into 8 ohms
TX/RX frequency.............................2400MHz – 2483.5MHz
Dimensions .................................9.75”H x 13” W x 3.5” D
(248 mm x 330 mm x 89 mm)
Weight .....................................3.25 lbs (1.47 kg) maximum
Headset
Battery type .................................3.6V Lithium ion
Battery life ..................................11 - 13 hours (typical)
RF frequency ................................2400MHz – 2483.5MHz
Weight .....................................3.53 oz (100 gm) with battery
Battery Charger
Voltage input ................................16.5VAC
Charging time................................2.5 hrs maximum
Dimensions .................................5.56” x 4.25” x 1.69”
(141mm x 108mm x 43mm)
Weight .....................................12.03 oz (341 gm) with bracket
