WIRING DIAGRAMS
102
14. WIRING DIAGRAMS
Full-Duplex Drive-Thru System with VDB but no Switcher Board
Page 103, Figure 29 — (Connections for Lane 1 or Single Lane)
Page 104, Figure 30 — (Connections for Lane 2 of Dual/Y-Lane or Tandem)
Full-Duplex Drive-Thru System with VDB, Switcher Board and IC300 Intercom
Page 105, Figure 31 — (Connections for Lane 1 or Single Lane)
Page 106, Figure 32 — (Connections for Lane 2 of Dual/Y-Lane or Tandem)
Full-Duplex Drive-Thru System with VDB, Switcher Board and Microphone
Page 107, Figure 33 — (Connections for Lane 1 or Single Lane)
Page 108, Figure 34 — (Connections for Lane 2 of Dual/Y-Lane or Tandem)
Half-Duplex Drive-Thru System with VDB but no Switcher Board
Page 109, Figure 35 — (Connections for Lane 1 or Single Lane)
Page 110, Figure 36 — (Connections for Lane 2 of Dual/Y-Lane or Tandem)
Half-Duplex Drive-Thru System with VDB and Switcher Board
Page 111, Figure 37 — (Connections for Lane 1 or Single Lane)
Page 112, Figure 38 — (Connections for Lane 2 of Dual/Y-Lane or Tandem)
Page 113, Figure 39 — Optional Equipment Connections
