EQUIPMENT DESCRIPTION
7
2.2.4 Correct Wearing of Belt-Pac
h The headset can be worn with the microphone on either side of your head.
h Wear the headset with its cable behind your back and attach the clothing clips to your collar
and shirt to keep the cable safely behind you, as shown in Figure 8.
h Hold the microphone boom at its base and adjust it so the microphone is near the side of
your mouth.
2.2.5 Battery Removal and Replacement
Figure 8. Correct wearing of the headset
Figure 9. Battery Removal
Hold microphone boom here to
adjust the microphone position
Clip
Battery
Battery-release
button
To change batteries:
If you hear “Battery low” or “Change battery”:
h Press the RELEASE BATTERY button on the belt clip of the pouch, and use your thumb to slide
the battery from the belt-pac.
h Place the battery in the battery charger for recharging.
h Install a fully charged battery in the belt-pac.
Note: You do not need to remove the pouch to remove or insert the battery.
