Scanreco G2 radio remote control system
16
HMF Technical Service Department
Rev.: 20-13
Menu item in CGW
5355
Description of functions and parameters
1.1.1.1.1.25.2.7
Min. Current
Indicates the minimum current in % of PWM Max Current for a solenoid valve. The
value is individually adjustable for each single PWM output so that the manual
control valve lever starts activation (flow from the port) when the remote control
lever in case of activation has just passed the dead band.
If a PWM output is used for ON/OFF control of a solenoid valve, the value is
adjusted at 0 %.
1.1.1.1.1.25.2.8
Max. Current
Indicates the maximum current in % of PWM Max Current for a solenoid valve. The
value is individually adjustable for each single PWM output so that the manual
control valve lever is just completely activated when the remote control lever in
case of activation is completely activated.
If a PWM output is used for ON/OFF control of a solenoid valve, the value is
adjusted at 100 %.
1.1.1.1.1.25.2.9
Ignore Dump
With the parameter Ignore Dump it is possible to select whether the current output
is to be deactivated when the dump valve is open (no dump signal).
Ignore Dump selected (ticked off) ⇒ The current output is not deactivated in case of
dump.
Ignore Dump not selected (not ticked off) ⇒ The current output is deactivated in
case of dump.
For example the work light (LIGHT) or functions used in stabilizer mode are not to
be turned off in case of dump.
