Configuration of remote control levers
By means of the CGW 5355 it is possible to configure which remote control lever that has to
activate the control valve functions.
It is possible to set up 12 different configurations in menu 1.1.1.1.2.8.1 - Lever function - ENT:
Lever setup 1-12. Press ENT For each Lever setup it is possible to configure 8 remote control
levers - Lever 1-8.
In menu 1.1.1.1.2.8.1.1.6 - Lever 1 - SET select which control valve function that has to be
operated from the remote control lever no. 1 from the left.
When the function has been selected, press ENT.
Select which control valve functions the other 7 remote control levers are to operate in the same
way.
Please see the table and the next chapter "Configuration of remote control levers, operation
direction".
Function
Description
None
Is selected if the remote control lever is not going to operate any function.
Std
The remote control lever operates the same function as selected in a previous
configuration (Lever setup).
Slew
The remote control lever is going to operate the slewing function.
Boom
Operation of boom function.
Jib
Jib function.
Ext
Extension function.
Fly-Jib
Fly-Jib - jib function.
FJ Ext
Fly-Jib - extension function.
Winch
Winch function.
W. park
Winch stowing function.
Rotator
Rotator function.
Grab
Grab function.
Cr.Aux.1
First extra control valve function.
Cr.Aux.2
Second extra control valve function.
Cr.Aux.3
Third extra control valve function.
Cr.Aux.4
Fourth extra control valve function.
Ex.1-16
The remote control lever is going to operate a control valve function for optional
extras. The function is by default proportional (PWM).
Stb.1-16
The remote control lever is going to operate an ON-OFF control valve function
for stabilizers.
