Scanreco G2 radio remote control system
29
HMF Technical Service Department
Rev.: 20-13
1.1.1.1.1.25.2.6 - Source Setup
ENT
- Setting up the signal type for the individual output
terminals for crane functions.
1.1.1.1.1.25.2.6.1 - K1.1
SET, arrow down
- Signal type for output terminal K1.1: A Prop
1.1.1.1.1.25.2.6.2 - K1.3
SET, arrow down
- Signal type for output terminal K1.3: B Prop
1.1.1.1.1.25.2.6.3 - K1.5
SET, arrow down
- Signal type for output terminal K1.5: A Prop
1.1.1.1.1.25.2.6.4 - K1.7
SET, arrow down
- Signal type for output terminal K1.7: B Prop
1.1.1.1.1.25.2.6.5 - K1.9
SET, arrow down
- Signal type for output terminal K1.9: A Prop
1.1.1.1.1.25.2.6.6 - K1.11
SET, arrow down
- Signal type for output terminal K1.11: B Prop
1.1.1.1.1.25.2.6.7 - K1.13
SET, arrow down
- Signal type for output terminal K1.13: A Prop
1.1.1.1.1.25.2.6.8 - K1.15
SET, arrow down
- Signal type for output terminal K1.15: B Prop
1.1.1.1.1.25.2.6.9 - K3.1
SET, arrow down
- Signal type for output terminal K3.1: A Prop
1.1.1.1.1.25.2.6.10 - K3.3
SET, arrow down
- Signal type for output terminal K3.3: B Prop
1.1.1.1.1.25.2.6.11 - K3.5
SET, arrow down
- Signal type for output terminal K3.5: A Prop
1.1.1.1.1.25.2.6.12 - K3.7
SET, arrow down
- Signal type for output terminal K3.7: B Prop
1.1.1.1.1.25.2.7 - Min. Current
ENT
- Setting up the minimum current for the individual
output terminals.
1.1.1.1.1.25.2.7.1 - K1.1
SET, type value
- Minimum current for "slew-right": 66%.
1.1.1.1.1.25.2.7.2 - K1.3
SET, type value
- Minimum current for "slew-left": 66 %
1.1.1.1.1.25.2.7.3 - K1.5
SET, type value
- Minimum current for "boom-down": 75 %
1.1.1.1.1.25.2.7.4 - K1.7
SET, type value
- Minimum current for "boom-up": 65 %
1.1.1.1.1.25.2.7.5 - K1.9
SET, type value
- Minimum current for "jib-up": 75 %
1.1.1.1.1.25.2.7.6 - K1.11
SET, type value
- Minimum current for "jib-down": 65 %
1.1.1.1.1.25.2.7.7 - K1.13
SET, type value
- Minimum current for "extension-out": 60 %
1.1.1.1.1.25.2.7.8 - K1.15
SET, type value
- Minimum current for "extension-in": 60 %
1.1.1.1.1.25.2.7.9 - K3.1
SET, type value
- Minimum current for "rotator-right": 60 %
1.1.1.1.1.25.2.7.10 - K3.3
SET, type value
- Minimum current for "rotator-left": 60 %
1.1.1.1.1.25.2.7.11 - K3.5
SET, type value
- Minimum current for "grab-open": 60 %
1.1.1.1.1.25.2.7.12 - K3.7
SET, type value
- Minimum current for "grab-close": 60 %
1.1.1.1.1.25.2.8 - Max. Current
ENT
- Setting up the maximum current for the individual
output terminals.
1.1.1.1.1.25.2.8.1 - K1.1
SET, type value
- Maximum current for "slew-right": 95 %
1.1.1.1.1.25.2.8.2 - K1.3
SET, type value
- Maximum current for "slew-left": 95 %
1.1.1.1.1.25.2.8.3 - K1.5
SET, type value
- Maximum current for "boom-down": 100 %
1.1.1.1.1.25.2.8.4 - K1.7
SET, type value
- Maximum current for "boom-up": 100 %
1.1.1.1.1.25.2.8.5 - K1.9
SET, type value
- Maximum current for "jib-up": 100 %
1.1.1.1.1.25.2.8.6 - K1.11
SET, type value
- Maximum current for "jib-down": 100 %
1.1.1.1.1.25.2.8.7 - K1.13
SET, type value
- Maximum current for "extension-out": 100 %
1.1.1.1.1.25.2.8.8 - K1.15
SET, type value
- Maximum current for "extension-in": 100 %
1.1.1.1.1.25.2.8.9 - K3.1
SET, type value
- Maximum current for "rotator-right": 100 %
1.1.1.1.1.25.2.8.10 - K3.3
SET, type value
- Maximum current for "rotator-left": 100 %
1.1.1.1.1.25.2.8.11 - K3.5
SET, type value
- Maximum current for "grab-open": 100 %
1.1.1.1.1.25.2.8.12 - K3.7
SET, type value
- Maximum current for "grab-close": 100 %
1.1.1.1.1.25.2.9 - Ignore Dump
ENT
- Setting up the output terminals, whether they are to
be active even if the RCL goes into stand by mode.
1.1.1.1.1.25.2.9.1 - K1.1

- Active in case of stand by (not ticked off).
1.1.1.1.1.25.2.9.2-12

- All the above-mentioned terminals must be active in
stand by mode (not ticked off).
1.1.1.1.2.4.1.1 - O1 K397
ENT
- Configuration of the RCL 5300 output terminal K397
for dump valve 1 (DMP1).
1.1.1.1.2.4.1.1.1 - Min current
SET, type value
- Set the minimum current for DMP1 at 0 mA.
1.1.1.1.2.4.1.1.2 - Max current
SET, type value
- Set the maximum current for DMP1 at 2000 mA.
1.1.1.1.2.4.1.1.3 - Signal
SET, arrow down
- Output signal for activation of dump valve 1 (crane
mode). Select: DMP1
