HMF Scanreco G2 - Monitoring Radio Remote Control System with CGW 5355

Scanreco G2 radio remote control system
37
HMF Technical Service Department
Rev.: 20-13
Monitoring of the radio remote control system by means of the CGW 5355
It is possible to monitor the output signals from the radio controller as well as feedback on spool
travel etc. by means of the CGW 5355 service terminal.
Please note! As always when monitoring, you need to press SET to read the values online.
Menu item in CGW 5355
Description
CGW command
1.4 - Monitor
- Monitor
ENT
1.4.3 - Output signals
- Output signals from controllers and sensors.
ENT
1.4.3.3 - Remote
- Output signals from the radio remote control system.
ENT
1.4.3.3.1 - 28
Button 1 - 28
- It is possible to monitor whether the RCL 5300 "sees" a
signal from the push buttons and tumbler switches
(please see the chapter "Setting up of output signals by
means of the CGW 5355") when they are activated on
the remote control box.
Press SET to
activate the CGW
online.
1.4.8 - Valve
- Monitoring of control valve functions.
ENT
1.4.8.1 - Valve sensing
- Monitoring of spool sensors.
ENT
1.4.8.1.1-14 - Slew……
- Monitoring of spool sensors, all crane functions.
Direction: A - Neutral - B.
SET
------------------------------
-------------------------------------------------------------------------
----------------
1.4.8.3 - Crane speed
- Monitoring of speed of crane functions. The activation in
percentage (0-100%) of the remote control levers.
ENT
1.4.8.3.1-15 - Slew……
- Monitoring of speed for all crane functions.
SET
------------------------------
-------------------------------------------------------------------------
----------------
1.4.8.4 - Spool position
- Monitoring of feedback from the electric activations of the
control valve about the activation in percentage (0-
100%)
of the spool.
ENT
1.4.8.4.1-15 - Slew…....
- Monitoring of the activation of the spool for all crane
functions.
SET
1.4.10 - Lever Function
- Monitoring of which crane functions are configured on
which remote control levers.
ENT
1.4.10.1-8 - Lev1……
- Monitoring of crane function on remote control lever 1-8.
