Scanreco G2 radio remote control system
50
HMF Technical Service Department
Rev.: 20-13
Error codes
Comment
RCL
display
LED display
in G2
Error code in
the RCL 5300
black box
Error
description
Cause
Remedy
185
02.01
0201
Incorrect voltage
on the DV
output.
Error in the DV
output. A low signal
is expected, but it is
high (perhaps
externally induced
voltage).
Check the DV output,
cable and plug. Remove
the plug and restart the
system.
171
02.02
0202
Short circuit on
the DV output.
The DV output is
short-circuited or
receives over
current.
Check the DV output,
cable and plug. Remove
the plug and restart the
system.
171
02.03
0203
Wrong voltage
for the safety
switch.
Incorrect voltage. A
low signal is
expected, but there
is a high signal.
The system carries out
automatic reset. Remove
all plugs and restart the
system.
171
02.04
0204
Short circuit of
the safety
switch.
Incorrect voltage. A
high signal is
expected, but there
is a low signal.
The system carries out
automatic reset. Remove
all plugs and restart the
system.
171
03.00
0300
Wrong voltage
on a digital
output.
Wrong voltage on
one of the digital
output terminals 1-
14. A low signal is
expected, but there
is a high signal.
The system carries out
automatic reset. Check all
digital output terminals.
Remove the plug and
restart the system.
171
04.00
0400
Short circuit on a
digital output.
There is a short
circuit on one of the
digital output
terminals 1-14. A
high signal is
expected, but there
is a low signal.
The system carries out
automatic reset. Check all
digital output terminals.
Remove the plug and
restart the system.
171
07.xy
----
Incorrect current
on an analogue
output
X=channel 1-16
Y=direction A or
B.
The third sequence
on the LED display
indicates which
output has an error.
1A, 1B……
The system carries out
automatic reset. Check all
analogue output
terminals. Remove the
plug and restart the
system.
170
08.01
0801
CAN in passive
mode.
CAN bus is in
passive mode.
The system carries out
automatic reset. Check
the CAN connections and
other CAN controllers in
the network.
170
08.02
0802
Too many CAN
data packets.
The CAN data
quantity is too large
on either a CAN
input or a CAN
output.
The system carries out
automatic reset. Check
both the CAN in-and
output as well as a CAN
controller connected to
the CAN output (if fitted).
170
08.03
0803
CAN working
again after being
interrupted.
The CAN
communication has
been in interrupted
condition.
The system carries out
automatic reset. Check
the CAN connections.
Check the controller
connected to the CAN
output (if fitted).
