159
Step 10
Install the High Pressure Water Hose and Grease the Thru-Shaft Bearings.
Apply anti-seize to the threads on the top of the thrust housing cap and install the high pressure water
hose. Hand tighten the hand nut on the pressure hose.
Use a grease gun and apply grease to the thru-shaft bearing until grease comes out of the relief hole
on the side of the thrust housing.
Pressure Water Hose
Hand Nut
Grease Fitting
Relief Hole
Figure 18: Thru-shaft bearing grease tting and grease
relief holes in thrust housing base.
Figure 17: Apply anti-seize to the thrust housing threads
and install the high pressure water line.
To Next Page
